MOZA Pedal Haptic Feedback Module

MOZA PHF Pedal Haptic Feedback Module

The MOZA PHF Pedal Haptic Feedback Module adds detailed, telemetry-driven vibration to compatible non-active pedal sets. With a motor capable of frequencies up to 100 Hz and adjustable effects in MOZA Pit House, it can reproduce feedback for ABS, traction control, engine RPM, wheel lock-up, wheel slip, gear shifts and more.

High-Performance Haptic Feedback

The module uses a high-performance motor capable of up to 100 Hz, delivering more detailed and responsive feedback than conventional 50 Hz solutions. Vibration frequency can be adjusted from 0 to 100 Hz and intensity from 0 to 100%.

Telemetry-Based Effects

• ABS activation
• Traction control
• Engine RPM vibration
• Wheel lock-up
• Wheel slip
• Gear-shift vibration
• Other configurable telemetry effects through MOZA Pit House

Compact and Easy to Install

The compact module measures 40 × 41 × 61 mm and can be installed on a throttle, brake or clutch pedal. For the most pronounced haptic feedback experience, MOZA recommends installation on the brake pedal.

Compatible MOZA Pedals

The module is compatible with MOZA non-active pedal sets including SR-P Lite, SR-P, SR-P2 and CRP2 pedals.

Independent Control Box

A dedicated control box manages the haptic module. Signal transmission can be made directly to a PC or through a compatible MOZA wheel base. The control box measures 80 × 66 × 26 mm.

Connection and Installation

The supplied manual documents installation on SR-P Lite, SR-P, SRP2 and CRP2 pedals using the included L-shaped mounting bracket and the specified screws. The module connects to the corresponding THROTTLE, BRAKE or CLUTCH port on the control box, while the pedal set connects to its PEDAL port.

Signal transmission supports two methods: through a PC or through a wheel base. Do not connect the control box to the PC and wheel base at the same time. Use only one connection method.

Open Ecosystem

When connected directly to a PC through the control box, the module can also be integrated with third-party non-active pedal sets using custom user-designed mounting solutions.

Secure Mounting

The high-strength integrated mounting bracket keeps the module securely mounted during intense braking and high-load driving conditions.

MOZA Pit House Configuration

MOZA Pit House supports effect selection, axis-related configuration where applicable, and adjustment of haptic feedback frequency and intensity to match each driver's preferences.

Kit and Module Configuration

At least one MOZA Pedal Haptic Feedback Kit is required to enable the full functionality of the Pedal Haptic Feedback system. Each kit includes one module and one control box. To equip all three pedals, use one kit together with two additional modules.

Frequently Asked Questions

Which pedals are compatible with the module?

The module is compatible with MOZA SR-P Lite, SR-P, SR-P2 and CRP2 non-active pedal sets.

Where can the module be installed?

It can be installed on the throttle, brake or clutch pedal. MOZA recommends the brake pedal for the best haptic feedback experience.

Is a control box included with the module?

The official MOZA product page states that a MOZA PHF Control Box is required and is not included with the module. If you do not already own a control box, choose the MOZA Pedal Haptic Feedback Kit.

How can I equip all three pedals?

One MOZA Pedal Haptic Feedback Kit and two additional modules are required to equip the brake, clutch and throttle pedals.
