Fanatec Podium Pedals Mounting Plate and Heel Rest

Fanatec Podium Pedals Mounting Plate and Heel Rest – Rigid Aluminium Foundation for Podium Pedals

The Fanatec Podium Pedals Mounting Plate and Heel Rest is an extruded aluminium mounting plate that provides the most stable foundation for your Podium Pedals, with integrated T-nuts for precise pedal spacing and an adjustable, removable Heel Rest. Built for serious braking, the rigid aluminium construction stays planted even under maximum braking force and can even add rigidity to your cockpit setup. The integrated T-nuts and defined mounting positions simplify installation, while the 4 mm-thick steel Heel Rest adjusts for height, distance and angle to dial in the perfect driving position — or removes entirely for use with the Podium Pedals Formula. Built around the standard Fanatec pedal mounting pattern.

Main Features

• Extruded aluminium mounting plate — the most stable foundation for Podium Pedals, staying planted under maximum braking force and adding rigidity to your cockpit setup
• Integrated T-nuts — allow precise adjustment of pedal spacing with defined mounting positions for simple installation
• Removable Heel Rest — made from 4 mm-thick steel plate, adjustable for height, distance and angle, or removed entirely for use with the Podium Pedals Formula
• Supports 2- and 3-pedal configurations — works with both Podium Pedals layouts
• Integrated mounting points for the connection box — keeps your setup tidy
• Standard Fanatec pedal mounting pattern — broad compatibility with Fanatec and third-party cockpits

Technical Specifications

• Product: Fanatec Podium Pedals Mounting Plate and Heel Rest
• SKU: CRD-9900028-WW
• Mounting Plate Material: Extruded aluminium
• Heel Rest Material: 4 mm-thick steel plate
• Heel Rest Adjustment: Height, distance and angle (removable)
• Pedal Spacing: Adjustable via integrated T-nuts
• Pedal Configurations: 2- and 3-pedal
• Connection Box: Integrated mounting points
• Mounting Pattern: Standard Fanatec pedal mounting pattern

What's in the Box

• 1x Podium Pedals Mounting Plate
• 1x Heel Rest
• 1x Extra-long Allen key
• 12x M6 T-nut (preinstalled)
• 4x washer + 4x M6 x 10 mm bolt (Heel Rest mounting)
• 4x M6 x 25 mm bolt + 4x washer + 4x M6 flange nut (hard mounting)

Compatibility

• Podium Pedals
• Podium Pedals Formula (without Heel Rest)
• CSL Cockpit / CSL Cockpit V1.5
• ClubSport GT Cockpit
• RennSport Cockpit
• Most third-party cockpits that support the Fanatec pedal mounting pattern

Important Notes

• A 10 mm wrench is required to tighten the hard mount (not included).
• M6 T-nuts are required for mounting to aluminium profile extrusions (not included).
• The 4 mm steel Heel Rest cannot be used together with the carbon fiber heel cups supplied with the Podium Pedals Formula. You choose between the steel Heel Rest and the carbon fiber heel cups.

Frequently Asked Questions

Which pedals is the Podium Pedals Mounting Plate compatible with?
It is designed for the Podium Pedals (2- and 3-pedal configurations) and the Podium Pedals Formula (without the Heel Rest). It uses the standard Fanatec pedal mounting pattern, so it also fits the CSL Cockpit, CSL Cockpit V1.5, ClubSport GT Cockpit, RennSport Cockpit and most third-party cockpits supporting that pattern.

Is the Heel Rest adjustable?
Yes. The removable Heel Rest is made from 4 mm-thick steel plate and adjusts for height, distance and angle, so you can dial in your ideal driving position. It can also be removed entirely for use with the Podium Pedals Formula.

Can I use the steel Heel Rest with the Podium Pedals Formula carbon fiber heel cups?
No. The steel Heel Rest and the carbon fiber heel cups supplied with the Podium Pedals Formula cannot be used together. You choose one or the other depending on your preferred setup.

Do I need any tools or extra parts that aren't included?
A 10 mm wrench is required to tighten the hard mount (not included). If you are mounting to aluminium profile extrusions, M6 T-nuts are required and are not included.

Does the Mounting Plate add rigidity to my setup?
Yes. The extruded aluminium construction creates a rigid platform that stays planted even under maximum braking force, and can add rigidity to your overall cockpit setup.
