Conspit MAX 01 Formula Steering Wheel

Conspit MAX 01

The Conspit MAX 01 is a Formula wheel built around a 4-inch 800 × 480 touchscreen compatible with SimHub. Its 5 mm carbon front panel and one-piece aluminium chassis carry 10 RGB buttons, 4 encoders, 4 dual-mode 12-position rotary switches, 2 joysticks, rear thumb buttons, 29 RGB LEDs, silent magnetic Hall shifters and two analogue Hall clutch paddles. It weighs 1400 g and fits most bases thanks to its Quick-Con 70 mm adapter.

Key features

• 4-inch 800 × 480 touchscreen, SimHub dashboards and Conspit pages
• 29 RGB LEDs: 15 RPM, 6 status, 8 multifunction
• 10 RGB buttons and rear thumb buttons
• 4 encoders and 4 dual-mode 12-position rotary switches, rotary macro function
• 2 7-way joysticks
• Silent magnetic Hall shifters and 2 analogue Hall clutch paddles
• 5 mm carbon front panel and one-piece aluminium chassis, metal knobs, TPU grips

Technical specifications

• Dimensions: 300 × 170 × 87 mm
• Weight: 1400 g (without quick release or adapter)
• Materials: carbon fibre front panel, aluminium alloy body
• Display: 4-inch 800 × 480 touchscreen
• LEDs: 29 RGB
• Buttons: 10 RGB
• Encoders: 4
• Rotary switches: 4 × 12-position
• Joysticks: 2 × 7-way
• Connection: direct USB or Conspit CAN
• Software: SimHub, Conspit Link 2.0

In the box

• Conspit MAX 01 steering wheel
• Quick-Con 70 mm adapter and detachable coiled USB cable
• User manual

Important notes

The quick release on the base side is not included: use the one from your base, or the optional Conspit quick release for Ares bases.

Compatibility

• PC Windows only. Not compatible with Xbox or PlayStation.
• Any base with a 70 mm quick release via the Quick-Con adapter
• Conspit Ares bases via the optional Conspit quick release
• SimHub for the touchscreen, LEDs and buttons

Which model to choose

• Conspit 310 Apex: 310 mm round GT wheel, 2.99-inch screen, interchangeable rims, Quick-Con or CDR version.
• Conspit 300 GT: 300 mm GT wheel in carbon and aluminium, 1150 g, 2.99-inch screen, 56 LEDs.
• Conspit 290GP: Formula wheel, 4.3-inch screen, MagFlip push/pull paddles.
• Conspit MAX 01: Formula wheel, 4-inch touchscreen, 29 LEDs.
• Conspit PW1: limited-edition 280 mm full-carbon Formula wheel, CDP included.
• Conspit H.AO Hub: carbon hub with screen, to pair with a 70 mm rim (RX320, DX320, CX295).

FAQ

Is the screen of the MAX 01 a touchscreen?

Yes. The Conspit MAX 01 has a 4-inch 800 × 480 touchscreen. It displays Conspit dash pages and SimHub dashboards, which you can customise.

Is the MAX 01 compatible with my base?

Yes, with most bases. The Conspit MAX 01 uses a 70 mm Quick-Con adapter with USB cable, so it fits bases from other brands with their own quick release, and Conspit Ares bases with the optional Conspit quick release.

What is the difference between the MAX 01 and the 290GP?

Both are Conspit Formula wheels. The MAX 01 has a 4-inch touchscreen, 29 LEDs, 10 RGB buttons and 4 rotary switches. The 290GP has a 4.3-inch screen, 12 RGB buttons and patented MagFlip push/pull paddles.

Are the buttons and LEDs of the MAX 01 customisable?

Yes. All RGB buttons and LED zones of the Conspit MAX 01 are programmable in SimHub, and encoder remapping and rotary macros are set in Conspit Link 2.0.

Does the Conspit MAX 01 work on PS5 or Xbox?

No. The Conspit MAX 01 works on PC Windows only.

Who handles warranty and after-sales service?

The French Simracer handles after-sales service for the Conspit MAX 01, as for every brand it sells, with a contact based in France. You never deal with the manufacturer directly. The product carries the 2-year legal warranty, or the manufacturer warranty if longer.
